electrical motor 4214
$29.80
SDF4214-380KV
• Net.weight (G)：195g
• Diameter * Length (mm)：Φ49×58.7
• Stator size (mm)：Φ42×14
• Spindle thread (D)：M5
• propeller mounting holes：5mm
• Motor mounting holes：30*30 4-M4
• confi-guration：12N14p
• Working voltage (V)：4s~8s / 16V~32V
• Rated current (A)：34A
• Max continuous current (A)：42A
• Max continuous power (w)：1312w
• Idle current (A)：1.45A
• Motor Efficiency (%)：90%
• No. of celles (Lipo Battery)：4s~8s Lipo
• Internal Resistance (mΩ)：42
• Motor cable Length (mm)：350
| Item NO. |
propeller | Throttle |
RpM |
volts (v) |
Amps(A) |
watts (w) |
Thrust(G) |
Efficiency (g/w) |
Operating temperature (℃) |
| D4214-380KV | 13x8x3 | 10 | 1066 | 33.85 | 0.3 | 9.8 | 65 | 6.77 | 55℃ |
| 20 | 2300 | 33.7 | 0.89 | 28.48 | 210.6 | 7.39 | |||
| 30 | 3360 | 33.63 | 1.63 | 53.44 | 495.2 | 9.26 | |||
| 40 | 4365 | 33.52 | 3.53 | 112.96 | 855 | 7.57 | |||
| 50 | 5762 | 33.42 | 6.48 | 203.76 | 1435 | 6.49 | |||
| 60 | 6670 | 33.32 | 10.6 | 339.2 | 1856 | 5.47 | |||
| 70 | 7746 | 33.21 | 15.9 | 508.8 | 2490 | 4.89 | |||
| 80 | 8548 | 33.09 | 22.63 | 748.8 | 3266 | 4.36 | |||
| 90 | 9468 | 32.8 | 31.3 | 1028 | 3860 | 3.87 | |||
| 100 | 10300 | 32.53 | 41.3 | 1321.6 | 4510 | 3.41 |
